Feldspar Powder Making Machine
![](/d/file/gm/2018-09-15/c0e91e825c447be94d9130e9c0ac52b0.jpg)
![Feldspar Powder Making Machine2](/d/file/gm/2018-09-15/2c31b0d022fb4d0ad6b5136f22a1aa1f.jpg)
Product Description
Overview
HGM Series Feldspar Powder Making Machine is the new type mining equipment for making micro powders, fine powders,which is widely applied in the industries of metallurgy, mining, chemistry, cement, construction, refractory materials, ceramics, and so on.The purpose of the micro powder grinding mills for super-fine grinding materials with hardness less than 9 in Moh's scale and humidity less than 6 percent such as kaolin, limestone, calcite, marble, talcum, barite, gypsum, dolomite, bentonite mud, mica, pyrophyllite, sepiolite, carbon black, diatomite, graphite, alunite, fluorite, potassium feldspar, phosphorite, pigment, up to 200 kinds.
![Feldspar Powder Making Machine1](/d/file/gm/2018-09-15/7398fe3f6007316deb6ae5850dd709d9.jpg)
Production line of Feldspar Powder Making Machine
consists of hammer crusher, bucket elevator, storage hopper, vibrating feeder, main unit, inverter classifier, cyclone collector, pulse deduster system, high pressure positive blower, air compressors and electrical control systems.
![production line of Feldspar Powder Making Machine.jpg](/d/file/gm/2018-09-15/547dd812eb474900a762ed5bd415a266.jpg)
Working Principle of Feldspar Powder Making Machine
When the grinding mill is at work, all the grinding rollers are rolling in the ring, and the materials are driven to the edge of the turn plate by the centrifugal force and fall down into the grinding chambers where the materials are repeatedly pressed, crushed and grinded by the rollers.
The high-pressure air blower constantly inhales air within the grinding mill and, in turn, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders, with airflow, moves to the dust cleaner, and clings to the surface of the filter bags. At the same time, the fine powders clinging to the surface fall down by the sudden vibration of the filter bags, which is caused by the instantly ejected high-pressure gas controlled by the pulse valve. The materials from the above two lots are sent by the conveyor at the bottom to get finished powders packed. In addition, filtered clean air will be emitted from the air outlet of muffler in the end.
The high-pressure air blower constantly inhales air within the grinding mill and, in turn, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders, with airflow, moves to the dust cleaner, and clings to the surface of the filter bags. At the same time, the fine powders clinging to the surface fall down by the sudden vibration of the filter bags, which is caused by the instantly ejected high-pressure gas controlled by the pulse valve. The materials from the above two lots are sent by the conveyor at the bottom to get finished powders packed. In addition, filtered clean air will be emitted from the air outlet of muffler in the end.
Certifications
We are adhering to innovation,quality assurance,customer-oriented principle,and the introduction of a large number of highly qualified technical personnel,making the company after years of development from a professional mill production system received CE certification and other qualifications.
![Feldspar Powder Making Machine3](/d/file/gm/2018-09-15/cdbadc232b95a9aab59b5033260997a1.jpg)
Specifications
Model
|
HGM80
|
HGM90
|
HGM100
|
HGM125
|
HGM168
|
Ring Diameter(mm)
|
800
|
900
|
1000
|
1250
|
1680
|
Ring Number (PCS)
|
3
|
3-4
|
4
|
4
|
4
|
Roller Number(PCS)
|
18-21
|
24-29
|
28-36
|
30-44
|
30-40
|
Main Shaft Speed (r. p. min)
|
230-240
|
200-220
|
180-200
|
135-155
|
120-130
|
Input Size (mm)
|
≤10
|
≤10
|
≤15
|
≤15
|
≤20
|
Finished Size (um/mesh)
|
74-5
(200-2500) |
74-5
(200-2500) |
74-5
(200-2500) |
100-6
(150-2000)
|
100-9
(150-1500)
|
Capacity (t/h)
|
0.4-4.5
|
0.6-6.5
|
1-9
|
2-16
|
3.8-30
|
Outlet Size L*W*H (m)
|
13.9*4*6.2
|
14.7*4.8*7.2
|
18*4.6*8.6
|
14*9*10.25
|
26.3*7.5*11.9
|
Our Service
![Feldspar Powder Making Machine4](/d/file/gm/2018-09-15/80f14cb9276c0654c38e823a6a02d419.jpg)
Pre-sales service
01/Online interactive service
Your consulting are always welcomed. You can contact us on the website online service, Skype, MSN, Google Talk.
02/Offline interactive service
We have already established our own social network service, including Facebook, Linkedin, Twitter, Google+,Youtube, etc.
03/Solution design service
Our engineer will also go to clients’ work site for the best solution drawing. We always customize solution for you. Your satisfaction is always our pursuit.
04/Visit reception service
You are always welcomed to visit Clirik! Our factory is just 15 minutes far away from International Airport. We will pick you up at the airport and we will reserve a comfortable hotel for you.
Your consulting are always welcomed. You can contact us on the website online service, Skype, MSN, Google Talk.
02/Offline interactive service
We have already established our own social network service, including Facebook, Linkedin, Twitter, Google+,Youtube, etc.
03/Solution design service
Our engineer will also go to clients’ work site for the best solution drawing. We always customize solution for you. Your satisfaction is always our pursuit.
04/Visit reception service
You are always welcomed to visit Clirik! Our factory is just 15 minutes far away from International Airport. We will pick you up at the airport and we will reserve a comfortable hotel for you.
After-sales service
01/ Installation and debugging service
We have a professional and experienced oversea installation team. So far they have successfully finished installation and commissioning for thousands of projects.
02/Training service
We do not only install and debug machine for our clients, but also train the worker, so they can operate the machine independently.
03/Other more service
Clients have any needs or problems; our engineer can take plane and get the work site to provide service in 48 hours.
We have a professional and experienced oversea installation team. So far they have successfully finished installation and commissioning for thousands of projects.
02/Training service
We do not only install and debug machine for our clients, but also train the worker, so they can operate the machine independently.
03/Other more service
Clients have any needs or problems; our engineer can take plane and get the work site to provide service in 48 hours.
![Feldspar Powder Making Machine5](/d/file/gm/2018-09-15/7ccb77146f391e06eadd6be61f07f712.jpg)
Packing & Delivery
![Feldspar Powder Making Machine6](/d/file/gm/2018-09-15/1e9eefcbafaca1f7e567118bf78d8c7e.jpg)
Packaging
|
|
Material
|
Wooden box
|
Weight
|
1.2 T
|
Packaging Details
|
The normal package is wooden box(Size: L*W*H). If export to European countries,the wooden box will be fumigated.If container is too tighter,we will use pe film for packing or pack it according to customers special request.
|
Our engineers will be responsible for monitoring the packaging and installing it overseas .We have a professional and experienced oversea installation team.Our engineers will install the products for you.And they will not leave until our clients are satisfied with our machine.
